The Liquid Filling Machine series is specifically designed for small production lines and customized filling requirements, catering to factory needs. We offer comprehensive customization and maintenance services to enhance production efficiency and stability. Whether handling highly fluid liquids or viscous products with particles, this machine achieves flexible and diverse filling through advanced piston or servo control technology. This series is suitable for multiple industries, including food, cosmetics, detergents, biotechnology, and chemical liquids, providing flexible and practical solutions. For startups, small factory production lines, and customized products, a precise metering system and an intuitive human-machine interface (HMI) ensure stable and reliable filling processes is stable and reliable.
Products Menu
- AST Cup / Tray Filling & Sealing Machine
- BST Continuous Tray Bean Curd Filling & Sealing Machine
- CST Cup Filling & Sealing Machine
- FST Cup / Tray Filling & Sealing Machine (Pre-cut Foil Sealing)
- RSM Rotary Cup Filling & Sealing Machine (Roll Film Type)
- RDM Rotary Cup Filling & Sealing Machine (Pre-cut Lid Type)
- ST Semi-auto Square Tray Sealing Machine
- AICF Automatic Ice Cream Filling & Sealing Machine
Semi-automatic Liquid & Paste Filling Machine
PF Liquid Filling Machine
PF-1 / PF-2 / PF-3
ADVANTAGES
FEATURES
-
Accurate Filling System:
Stable volumetric filling ensures consistent capacity for every unit, reducing errors and material waste. -
Container Versatility:
Compatible with various container formats including bags, bottles, aluminum pouches, tubes, and more. -
Modular Design:
Expandable filling heads and customizable operation interfaces provide flexibility for different production lines. -
Easy-to-Clean Design:
Complies with food-grade requirements; filling components can be quickly disassembled for cleaning to prevent cross-contamination. -
Simplified Operation:
User-friendly operation featuring automatic calibration and anomaly alert functions. Optional Equipment:
Available with heating systems, CIP (Clean-in-Place) systems, and more to meet diverse professional needs.Simple Operation, Quick Start:
Requires only one operator, featuring intuitive designs such as foot-pedal start and one-touch filling.High Liquid Adaptability:
Suitable for watery liquids, alcohol, disinfectants, serums, lotions, and high-viscosity liquids.High Precision, Low Error:
Utilizes high-quality pneumatic/electronic control systems paired with stainless steel precision valves, achieving ±1% accuracy.Compact & Easy Installation:
Ideal for production sites with limited space; plug-and-play setup without the need for large-scale construction.Convenient Maintenance:
Made of food-grade stainless steel with a simple disassembly structure for fast daily cleaning and maintenance.
APPLICATIONS
- Cosmetics & Personal Care: Lotion, essence, facial cleanser, makeup remover.
- Food & Beverages: Fruit juice, fruit vinegar, sauces, dairy drinks, concentrates, beverages, soy milk, jelly.
- Cleaning Products: Disinfectant, hand sanitizer, antiseptic solution, fabric softener, alcohol, hair dye.
- Chemical & Industrial: Lubricants, solvents, acidic or alkaline liquids, anti-rust fluids.
SPECIFICATIONS
|
Model
Spec.
|
PF-1 | PF-2 | PF-3 |
|---|---|---|---|
| Filling Range | 100g-500g | 500g-1000g | 1000g-2000g |
| Packaging Speed (BPM) | 25-30 | 15-20 | 5-15 |
| Electric Power | AC 220V | ||
| Air Compressor | 2 HP | 3 HP | |
※ Note: The air compressor required for this machine must be provided by the customer.
Need sizing or a quotation?
Request a Quote
PF Liquid Filling Machine
Share your material, pack format, and capacity target. The SAN TUNG team will help match the right machine configuration.
